By default, runBanksyPCA uses a lazy linear operator
that computes PCA without materializing the full BANKSY matrix. This is
memory-efficient and recommended for most use cases.
However, some workflows require explicit construction of the BANKSY
matrix — for example, when using the azimuthal Gabor filter (AGF), when
access to the intermediate matrices is needed, or when using higher
harmonics (M > 0). This vignette demonstrates the
standard workflow using computeBanksy followed by
runBanksyPCA(lazy=FALSE).
library(Banksy)
library(SummarizedExperiment)
library(SpatialExperiment)
library(scuttle)
library(scater)
library(cowplot)
library(ggplot2)Data preprocessing
We use the mouse hippocampus dataset provided with Banksy.
Initialize a SpatialExperiment object and perform quality control and normalization.
se <- SpatialExperiment(assay = list(counts = gcm), spatialCoords = locs)
# QC based on total counts
qcstats <- perCellQCMetrics(se)
thres <- quantile(qcstats$total, c(0.05, 0.98))
keep <- (qcstats$total > thres[1]) & (qcstats$total < thres[2])
se <- se[, keep]
# Normalization to mean library size
se <- computeLibraryFactors(se)
aname <- "normcounts"
assay(se, aname) <- normalizeCounts(se, log = FALSE)Computing the BANKSY neighborhood matrices
computeBanksy computes the neighborhood matrices and
stores them as assays in the SpatialExperiment object. Setting
compute_agf=TRUE computes both the weighted neighborhood
mean
()
and the azimuthal Gabor filter
().
The number of spatial neighbors used to compute
and
are k_geom[1]=15 and k_geom[2]=30
respectively.
k_geom <- c(15, 30)
se <- computeBanksy(se, assay_name = aname, compute_agf = TRUE, k_geom = k_geom)
#> Computing neighbors...
#> Spatial mode is kNN_median
#> Parameters: k_geom=15
#> Done
#> Computing neighbors...
#> Spatial mode is kNN_median
#> Parameters: k_geom=30
#> Done
#> Computing harmonic m = 0 with 15 neighbors
#> Done
#> Computing harmonic m = 1 with 30 neighbors
#> Centering
#> DoneAfter running computeBanksy, the neighborhood matrices
are accessible as assays:
assayNames(se)
#> [1] "counts" "normcounts" "H0" "H1"PCA, clustering, and visualization
We run PCA with lazy=FALSE to use the standard path,
which constructs the full BANKSY matrix via
getBanksyMatrix. Setting use_agf=TRUE uses
both
and
.
We compare non-spatial clustering (lambda=0) with BANKSY
cell-typing (lambda=0.2).
lambda <- c(0, 0.2)
set.seed(1000)
se <- runBanksyPCA(se, use_agf = TRUE, lambda = lambda, lazy = FALSE)
se <- runBanksyUMAP(se, use_agf = TRUE, lambda = lambda)
se <- clusterBanksy(se, use_agf = TRUE, lambda = lambda, resolution = 1.2)
se <- connectClusters(se)
#> clust_M1_lam0.2_k50_res1.2 --> clust_M1_lam0_k50_res1.2Visualise the clustering output:
cnames <- colnames(colData(se))
cnames <- cnames[grep("^clust", cnames)]
colData(se) <- cbind(colData(se), spatialCoords(se))
plot_nsp <- plotColData(se,
x = "sdimx", y = "sdimy",
point_size = 0.6, colour_by = cnames[1]
)
plot_bank <- plotColData(se,
x = "sdimx", y = "sdimy",
point_size = 0.6, colour_by = cnames[2]
)
plot_grid(plot_nsp + coord_equal(), plot_bank + coord_equal(), ncol = 2)
Accessing the BANKSY matrix
The full BANKSY matrix can be retrieved with
getBanksyMatrix. This is useful for custom downstream
analyses.
banksy_matrix <- getBanksyMatrix(se, M = 1, lambda = 0.2,
assay_name = aname, scale = TRUE)
dim(banksy_matrix)
#> [1] 360 10205Session information
